Touchscreen 42"

3M Touch, 9013, Dst Touch System, 42" Screen, 42" Sensor, Dst Controller, Dual Mode, 12" Flex Tail

System Performance

Input Method

 Finger and stylus input

 Accuracy

 Reported coordinates are within 1.0% of true

 position (based on viewing area dimensions)

 Touch System Resolution

 16k x 16k (maximum resolution)

 Response Time

 20 ms for tap input

 Minimum Touch Impact*

 50 mN?s (milli-newton seconds), the equivalent

 of a very light touch

Optics

 Light Transmission**

 92% light transmission (±2%)

 Surface Finish

 Anti-glare etch (standard)

Mechanical

 Glass Thickness

 2.2 mm (± 0.2 mm), glass only

 Overall Thickness

 4.4 mm (± 0.5 mm)

 Includes glass thickness, tail, electronics

 components, and mounting material

 Substrate Material

 Chemically-strengthened glass substrate

 Surface Hardness

 Mohs pick with a hardness rating of 7 or

 higher is required to induce a scratch.

 Scratches will not result in a functional failure

 Cleaning

 Recommended 50:50 isoproply alcohol and

 water solution

Reliability

 Surface Obstructions

 Touch screen operation withstands surface

 contaminants such as dirt, dust and grime

 Operating Temperature***

 -15° C to +70° C for the touch screen

 RH: Up to 90% non-condensing

 Storage Temperature***

 -50° C to +85° C

 RH: Up to 90% non-condensing

Electronics (3M MicroTouch Controller DX)

 Communications

 Auto-sensing dual mode

 Protocol

 (Serial plug and play and/or USB HID)

 Nominal Uncased

 2.66" x 3.75" x 0.45"

 Dimensions

 67.56 mm x 95.25 mm x 11.43 mm

 MTBF (average)

 >140k hours per MIL Std. 217F calculation

 Regulatory

 IEC/UL 60950-1, FCC-A, CE, VCCI, AS/NZS 3548

 Drivers

 MicroTouch MT7 for Microsoft

 Windows

 2000, XP and VISTA


Herstellernummer: DSTK9013-3420
